Mô tả sản phẩm
| Storage conditions Temperature Relative humidity |
• -25 to +85ºC • 0% to 95%; no condensation |
| Operating conditions Temperature Relative humidity |
• -20 to +50ºC • 0 to 95%; no condensation |
| Mains connection Voltage | • 220-240VAC; 50/60Hz |
| Mains surge immunity | • 1kV/2kV |
| Power consumptionStand-by | • <1.5W |
| Maximum load Load peak inrush current |
• 4 A (Resistive load) • 100A |
| Applicable wire range | • 0.75 to 1.5mm2 |
| Switch off delay Light levels Detection range Angel blocker |
• 2(default)/ 5 / 15 / 30 minutes • Disable /10 /30 /100lux • See diagram • Available |
| Certification Protection Class Lifetime |
• CE •IP20 • 50,000 hrs |
| Box dimensions (mm) | • SES LCM1060 Unit box: 105 x 75 x 105 • SES LCM1060 Outer box: 390 x 220 x 122 |
